*1x VGA(WUXGA)/1xVGA Out(hold during power off)
*Up to 1920x1200
*SRT/RTSP/RTMPS/UDP/NVR etc
*Private Low Lantency Protocol UTP
*Video Rotate,Flip,Mirror,Clip
*Separate Audio or Video Stream
*Play Stream on Browser
*Customizable
Video |
|
Input/Output Loop |
1x VGA(WUXGA)/1xVGA（hold during power off） |
Resolution |
1920x1200P60,1920x1080@60P/50p,1920x1080@60i/50i/1280x720@60p/50p,1680x1050,1600x1200,1600x900,1440x900,1400x1050,1366x768,1360x768,1280x1024,1280x960,1280x800,1280x768,1280x720,1280x600,1152x864,1024x768,800x600 720x576i/720x480i,640x480,320x480,352x288,240x320,176x144,160x120,128x96,88x72 |
Encoding |
H.265/H.264/AVC |
Encoding Output FPS |
1080P60(only input 1080P60) |
Data Rate |
0.16Mbps~32Mbps |
Rate Control |
CBR/VBR |
GOP |
5-300 |
Advanced Pretreatment |
Video Rotate,Flip,Mirror,Clip |
Latency Time |
100ms |
Audio |
|
Input/Output Loop |
1x3.5mm/1.3.5mm |
Encoding |
AAC/AAC+/MP3/MP2/AC3/G711.A/G711.U |
Sampling rate |
44100/48000 Hz |
Bit-rate |
32K/48K/64K/96K/128K/160K/192K/384K |
Sampling precision |
24 bit |
System |
|
Ethernet |
1000M |
Protocol |
SRT UTP HTTP RTSP RTMP HLS FLV UDP multicast/unicast |
control interface |
Website |
Genernal |
|
Dimension (L×W× H) |
105x152(173)x28mm |
Net Weight |
0.3kg |
Temperature |
0-45(work),-20-80(storage) |
Power |
12V DC 1A |
Consumption |
5w |
