Video

Input

1x HDMI/12G-SDI

Resolution

4096x2160p60,3840x2160p60,2560x1440p144,1920x1080@60P/50p,1920x1080@60i/50i/1280x720@60p/50p 720x576i/720x480i

Encoding

H.265 HEVC/H.264/AVC

Encoding Output FPS

2160P60

Data Rate

0.32Mbps~64Mbps

Rate Control

CBR/AVBR/CVBR/Strong CBR

GOP Structure

5-300

Advanced Pretreatment

Video Clip/Brightness/Contrast/RGB

Latency Time

100ms

Colour gamut

BT.2020/BT.709/BT.601

Video Sample

10bit

OSD

3xImage or TXT or 1xscroll txt or Time

Audio

Input

1xHDMI/1x3.5mm

Encoding

AAC/AAC+/MP3/MP2/AC3

Sampling rate

44100/48000 Hz

Bit-rate

32K/48K/64K/96K/128K/160K/192K/384K

Sampling precision

24 bit

System

Network Interface

1000 Base-T Ethernet interface

Protocol

UTP SRT HTTP RTSP RTMP RTMPS HLS FLV UDP unicast/multicast

control interface

Website control/CGI

NTP

Support

Record

NTFS/exFAT/FAT32 USB3.0 Udisk or SSD or TF

Network Access

Samba

General

Dimension (W× L× H)

170x104x38mm

Net Weight

0.6kg/1.2kg

Temperature

0-45(work),-20-80(Storage)

Power

12V DC 2A

Consumption

10w
