3G-SDI Input with Level-B Support – Captures 1080p60 video with full compatibility for Level-B and Level-A standards; ideal for broadcast and professional AV workflows
Plug-and-Play USB 3.0 – External capture box, no internal installation required; connects via USB 3.0 for low-latency transmission with laptops or desktops
Crisp 1080p60 Capture – Delivers high-quality, smooth video at 60fps with embedded SDI audio support for professional recording and streaming
Broad Software Compatibility – Works with OBS, vMix, Wirecast, Zoom, Teams, VLC, and more; UVC-compliant for hassle-free integration
Please contact us to serve you!" >
| Interface | |
| USB interface | USB3.0, 360MB/s Bandwidth (Compatiable USB2.0) |
| Input interface | 1xSDI |
| Output interface | N/A |
| SDI Input | 1080P50/60, 1080I50/60, 720P50/60, 576P, 576I, 480P, 480I |
| Audio input | SDI embedded |
| System | Windows (7, 8, 8.1, 10), Linux (kernel version 2.6.38 and above), OS X (10.8 and above) |
| Standard | |
| HDMI input format | Support 1080P/60HZ 8-bit, (YUV) SD/HD/3G-SDI, SMPTE-259/274/296/372/424/425/292 compliance |
| Transmission speed | SDI: 1.485Gb/s, 2.97Gb/s |
| Video capture | UVC (USB video class) compliance |
| Audio capture | UAC (USB audio class) compliance |
| Output color space | YUY2/NV12/I420 |
| General | |
| Operation system | Support Windows 10/11, Android 5.0 above, Linux, Mac OS |
| Compatible software | Windows Media Encoder, Adobe Flash Media Live Encoder, Real Producer Plus, VLC, Wirecast, AMCAP etc. |
| Compatible dev. interface | DirectShow (Windows), DirectSound (Windows) |
| Update | Firmware can be updated by USB port |
| Dimension | 70x100x24mm |
| Box Dimension | 100x146x53mm |
| Net/Gross Weight | 0.2/0.3kg |
| Consumption | <= 3.5 W |
| Working Temperature | 0-50 degree |
| Storage Temperature | -20-70 degree |
| Storage humidity | 5%-90% |
