Ultra-HD Input: Supports up to 2160p30 (4K30)
1080p Recording: Records in 1920x1080, 1280x720, and 1280x1024 resolutions as MP4 (H.264).
Built-in 1TB SSD & Expandable Storage: Features a 7-inch monitor. Records directly to the built-in SSD, or external USB drives and SD cards.
Versatile Connectivity: Supports SDI HDMI, DVI, VGA, YPbPr, CVBS, and S-Video inputs.
Pro-Grade Accessories: Includes a full-function remote control and a hot-shoe mount. Battery not included (sold separately).
Please contact us to serve you!" >
| Specification | |
| Video Input | HDMI/3G-SDI/DVI/VGA/YPbPr/CVBS/Svideo |
| Input Resolution | 4096x2160p30(HDMI), 1920x1080@60P/50p, 1920x1080@60i/50i, 1280x720@60p/50p, 720x576i/720x480i |
| Loop Out | 1xHDMI |
| Audio | HDMI Embeded/External Audio/Line In/Mic In |
| Display Screen | 7 Inch |
| Remote Control | Yes |
| Screeshot in Recording | Yes |
| Playback | Yes |
| Foot Switch | Take Snapshot |
| Internal SSD | 1TB |
| Alone Mode | |
| Record Resolution | 1920x1080/1280x720/1280x1024/1024x768 |
| Storage Device | Flash USB Drive(up to 512G), Harddisk(up to 8T), SD(up to 512G) |
| Storage File System | FAT32/exFAT/NTFS |
| Record Format | MP4(H.264 Codec) |
| Video Bitrate | Low 4MB / Mid 10MB / High 18MB |
| Audio Bitrate | 128KB |
| Size of Each File | 4G(FAT32) or 16G(NTFS/exFAT) |
| Schedule Recording | Support |
| Storage Device Switch | Internal SSD / External SD or USB Flash Drive |
| Computer Mode | |
| Record Resolution | 1920x1080/1280x720/1280x1024/1024x768 |
| Compatible UVC/UAC | Yes |
| Comatible System | Win10/Mac OS/Linux |
| Compatibility with 3rd application software | OBS/Xsplit/Wirecast/FLME/QuickTime/VLC/Potplayer/Skype |
| Attached Software (separately to buy) | UXplayer |
| General | |
| Language | English / Chinese |
| Dimension (W×L×H) | 175x120x26mm |
| Package(W×L×H) | 222x214x57mm |
| Net/Gross Weight | 0.55kg / 1.2kg |
| Temperature | 0-55(Work), -20-80(Storage) |
| Power/Consumption | 12V DC 1.5A / 10w |
| Included in Package | |
| UR550 x1, Holder x1, DVI Cable 1.2M x1, DVI to HDMI Cable 1.2M x1, SDI Cable 1.2M x1, Svideo Cable 1.5M x1, Power Adapter x1, Remote Control x1, Foot Switch x1, Manual x1 | |
